MixRite TF5 CLPO Air Release
Download brochure
Tutorial

The MixRite can be used in the application of fertilizer and chemicals through an irrigation system. This technique can reduce fertilizer application costs. It may also improve nutrient efficiecy by applying them closer to when and where plants need them.

Technical Data

MixRite Type CL
Working Pressure 1-8 bar
Thread Type BSP
Thread Size 1″
Water Pressure ‎1–8 bar [14.5 to 116 psi]
ON OFF System No [Air Release]
Dosage Rate ‎0.1%–1%
Flow Rate Range ‎100–5000 l/h [0.44 to 22 gpm]
Min Injection Per Hour 0.1 l/h [0.026 gph]
Max Injection Per Hour 50 l/h [13.2 gph]
Application Segment Irrigation|Industrial|Livestock
Material PP+FG
Min Pressure Loss 1 bar
Max Pressure Loss 8 bar
Foot Valve Optional
With Legs Optional
Connection Type Threaded
