Technical Data
| Unit type | Imperial |
|---|---|
| Material | Acetal |
| Thread Type | BSPT |
| Color | Black |
| Temperature Range | -20° C up to +90° C |
| Working Pressure | Up to 14 bar (200 psi) at +20° C |
| Tube OD mm | |
| Tube OD inch | 1/4″ |
| F BSPT | 1/4″ |
| SW mm | 17.5 |
Hydraulic and pneumatic systems mostly indoor applications. Quick assembly without dismantling the fittings. Allowing uninterrupted passage of water or air.
