MixRite 3.5 - PVDF - Air Release
Download brochure
Tutorial

The MixRite can be used in the application of fertilizer and chemicals through an irrigation system. This technique can reduce fertilizer application costs. It may also improve nutrient efficiecy by applying them closer to when and where plants need them.

Technical Data

MixRite Type PVDF
Working Pressure ‎0.2–8 bar
Thread Type BSPT
Thread Size 3/4″
Water Pressure ‎0.2–8 bar [3 to 116 psi]
ON OFF System No [Air Release]
Dosage Rate ‎0.3%–2%
Flow Rate Range ‎10–3500 l/h [0.04 to 15.5 gpm]
Min Injection Per Hour 0.03 l/h [0.008 gph]
Max Injection Per Hour 70 l/h [18.5 gph]
Application Segment Industrial
Material PVDF
Weight 4 pound [1.8 kg]
Gross Weight 1.9 kg [4.19 lbs]
