Technical Data
Unit type | Metric |
---|---|
Material | Reinforced Polypropylene |
Thread Type | BSPT |
Color | Blue |
Temperature Range | +4° C up to +90° C (+40° F up to +195° F) |
Working Pressure | Up to 14 bar (200 psi) at +20° C |
D | 21.5 mm |
C | 10 mm |
d small | 12 mm |
Carton Quantity | 250 |
L mm | 67 |
L1 mm | 36 |
Tube OD mm | 12 |
b small | 24 mm |
M BSPT | 1/2″ |
